Garmin STRIKER™ Vivid 9SV

The sonar color you pick says a lot about your fishing style. Good thing there are now seven new vivid options. Use the included transducer to get CHIRP international, Clear Vu and Side Vu sonars. You will never lose a hot spot again as you can use a waypoint to find your way back. The view under the water is amazing and its Wi-Fi connection on land opens up a whole new world of possibilities on the water.

Dimension: 11.1” x 6.5” x 2.4” (28.2 x 16.5 x 6.0 cm)

Weight: 2.4 lbs (1.1 kg)

Water rating: IPX7

Display type: WVGA color

Display Size: 4.4" x 7.8" (11.2 x 19.8 cm); 9.0" diag (22.8 cm)

Display resolution: 800 x 480 pixels

Mounting Options: flush, tilt/swivel

Input: Keyed

Maps & Memory

Waypoints/favorites/locations: 5000

Track points: 50,000

Tracks: 50

Navigation Routes: 100

Sensors

GPSHas built-in receiverSupports WAAS

Optional Map Support

Garmin Quickdraw Contours

Electrical Features

Power Input12 to 20 VdcTypical current draw0.75 AMax current draw1.5 APower Consumption9.0

Sonar Features

Displays sonarTraditional sonar (dual frequency/beam)Built-inClearVüSideVüFrequencyTraditional: 50/77/200 kHzCHIRP (mid and high)ClearVü and SideVü 260/455/800 kHzTransmit power500 W (RMS)Bottom Lock (shows return from the bottom up)Water Temperature Log

Connections

4-pin transducer ports2Garmin Wi-Fi network (local connection)

Fishfinder Features

Split-screen zoomFish Symbol ID (helps identify fish targets) Autogain technology (minimizes clutter; maximizes targets) Adjustable depth line (measures depth of underwater objects) A-scope (real time display of fish passing through transducer beam) Water temperature sensor included Depth range shading

• STRIKER Vivid 9sv fishfinder
• GT52HW-TM transducer
• Power/data cable
• 12-pin to dual 4-pin transducer adapter cable
• Tilt mount
• Hardware
• Garmin bumper sticker
• Documentation
